Cooler Master Case H500M HAF Elements Designs

Product details of Cooler Master MasterCase H500M E-ATX ARGB Gaming Case with Four Tempered Glass Side Panels

MasterCase H500M
MCM-H500M-IHNN-S00
Interchangeable Mesh/Glass Front Panel
360mm Radiator at Top and Front
Rich Connectivity with USB 3.1 (Gen 2) Type-C Support
Two Additional PCI slots at the Rear for Vertical GPU Positioning
Nine Management Covers for Clean Building
Dedicated Water Pump/ReservoirBracket offers Mounting Option atop the PSU Shroud
Graphics Card Support Arm
Two 200mm Addressable RGB Fans
Addressable RGB Controller

Specifications

Product Name	MasterCase H500M
Model Number	MCM-H500M-IHNN-S00
Available Color	Iron Grey
Materials	Outlook: Steel Mesh, Glass Body: Steel Side panel: Tempered Glass
Dimensions (LxWxH)	544 x 248 x 546mm / 21.4 x 9.8 x 21.5 inch
Motherboard Support	Mini-ITX, Micro-ATX, ATX, E-ATX (support upto 12" x 10.7")
Expansion Slots	7 + 2 (Support vertical graphics card installation)
5.25" Drive Bays	0
2.5" / 3.5" Drive Bays	2
2.5" SSD Drive Bays	6
I/O Port	USB 3.1 Type-C x 1 USB 3.0 Type-A x 4 Audio In & Out (supports HD Audio)
Pre-installed Fan(s) - Front	200mm ARGB Fan x 2 (Speed: 800RPM / Connector: 3Pin + ARGB 3pin)
Pre-installed Fan(s) - Rear	140mm fan x 1 (Speed: 1200RPM / Connector: 3Pin)
Fan Support - Top	120 fan x 3 or 140mm/200mm fan x 2
Fan Support - Front	120/140mm fan x 3 or 200mm fan x 2
Fan Support - Rear	120/140mm fan x 1
Liquid Cooling Support - Top	120mm, 140mm, 240mm, 280mm, 360mm (maximum thickness clearance 43mm)
Liquid Cooling Support - Front	120mm, 140mm, 200mm, 240mm, 280mm, 360mm (70mm clearance w/radiator lid & M.portremoved)
Liquid Cooling Support - Rear	120mm, 140mm
Clearance - CPU Cooler	190mm
Clearance - Graphics Card	412mm
Clearance - Power Supply	200mm
Power Supply Support	Bottom Mount, ATX PS2
